Complete Swisher ZTR2766BS 66-inch Mower Specs

66
-inch
cutting width
8
mph
Top Speed
3
-year
warranty
Avg. rating:
(64%) (11 reviews over 2 sources)

You Should Also Check Out: Top 10 Best Electric Lawn Mowers 2019
General Specs
Main categoryElectric lawn mower
Weight860lbs.
Warranty3 years

Performance
Top Forward Speed (mph)8
Top Reverse Speed (mph)8
Engine power Kw36.2
Horsepower27 HP
AlphaMetrics
Width (inches)76.5
Height (inches)46 (with ROPS folded down)
Width (mm)1943.1
Height (mm)1168.4
Mowing Features
Cutting width (inches)66
Cutting deck typeWelded steel
Cutting methodsSide discharge (optional bagger and mulch kit)
Cutting deck materialSteel
Deck thickness gauge11
Anti-scalp wheels3
Deck lifting systemFoot Operated, Spring Assisted
Blade engagementPTO switch
Blades3
Mower Cut Height (inches)5
Mower Cut Height Min (inches)1.5
Cut Height Increments count8
Cutting height adjustmentNotch (Foot Operated)
Lift systemFoot Operated, Spring Assisted
Mower Deck MaterialWelded steel
Mower Drive SystemBelt
Mower Wheels4
Spindle BushingsSteel
Under The Hood
Engine MakeBriggs & Stratton
Engine ignitionSwitch
Engine cylinders2
Engine coolingAir
Engine fuelGasoline
Fuel Tank Capacity (quarts)32
Fuel Tank Capacity (litres)30.28
Engine lubrication typeSAE 20w-50
Oli filter
Fan-cooled pumps
BatteryLead-acid
Battery voltage12 V
Drive Details
Steering typeZero turn
Interlock system
Drive system typeHydrostatic
Wheel typePneumatic
Front Tires12 x 6-6
Rear Tires20 x 10-10
Front Axle materialWelded steel
Transmission TypeHydrostatic
Transmission manufacturerHydro-Gear
Transmission controlLever-operated
Transmission coolingFan-cooled
Other Specs & Features
MSRP$6,599.95
User manualClick here
Country of assemblyUSA
UPC code728172399462
12 Volt Outlet
Covered Toolbox
Cupholder
Hourmeter
Chassis frameWelded steel
Receiver Hitch (front and rear)
Starter typeKey start (electric)
Fuel Tank Capacity8 gal. (Or 30.28L / 32 qts.)
Manufacture product IDZTR2766BS

Description:

With a 27hp motor powering a wider-than-average 66-inch cutting width, and with an 8-gallon fuel tank, the ZTR2766BS is comparable to a pro mower. A top speed of 8mph (for reverse too) and eight height adjustments ranging from 1.5 to 4.5 inches complement its features. Also noteworthy is the 11-gauge deck construction (which, by the way, is common to the 60-inch width category).

Also called Swisher 66-inch Briggs and Stratton.
