Most-complete Toro MX-5000 Mower Specs

cutting width
You Should Also Check Out: Top 10 Best Zero-turn Mowers 2020
Under The Hood
Engine MakeToro
Engine ModelV-twin with self-cleaning airbox
Cylinder displacement708 cc
Fuel Tank Capacity (quarts)12
Fuel Tank Capacity (litres)11.36
Engine power Kw32.2
Horsepower24 HP

Mowing Features
Cutting width (inches)50
Deck Wash Port
Mower Cut Height (inches)4.5
Mower Cut Height Min (inches)1.5
Mower Deck Material10-gauge fabricated steel
Drive Details
Steering typeZero-turn
Forward Speeds3
Reverse Speeds3
Front Tires13 x 5
Rear Tires18 x 9.5
Transmission TypeDual hydrostatic
Other Specs & Features
User manualClick here
SpecialRear engine guard, Automatic parking brake (A feature that engages the unit's park brake when the control arms are moved outward), Smart Speed control (Toro allows the users to choose from three ground speed ranges, specifically trim, tow and mow)
Covered Toolbox
Receiver Hitch
Fuel Tank Capacity3 gal. (Or 11.36L / 12 qts.)
Manufacture product ID74775
Release year2015
Release month10
Width (inches)53.5
Height (inches)39.1
Width (mm)1358.9
Height (mm)993.1
General Specs
Main categoryZero-turn lawn mower
Warranty3 years (No hour limitation)


Also known as: Toro MX5000, Toro 74775, Toro TimeCutter MX5000.
