Most-complete Briggs and Stratton 1022EX Snow Blower Specs

intake width
Our Score: 88%

Main sub-categoryGas snow blower cheaper than $500

Intake Specs
Intake dimensions22-inch wide x 12.5-inch deep (height)
Blower typeSingle-stage
Auger StyleSerrated SnowShredder
Auger Diameter10"
Auger materialSteel
Throwing Distance30 feet
Engine MakeBriggs and Stratton
Engine Model950 Snow Series
Engine Type4-cycle (OHV)
Cylinder displacement208 cc
Engine fuelGasoline with a minimum of 87 octane and up to 10-percent ethanol composition
Fuel Tank Capacity0.8 gal. (Or 3.03L / 3 qts.)
Gross Torque9.5 foot-lbs
Starter type
  • Push-button (It can start down at -20 degrees F)
  • Recoil
Chute / Deflector
Chute Deflector Direction ChangeCrank-controlled (It has a handle for changing the throwing height and distance)
Chute MaterialPlastic
Chute Rotation200 °
Propulsion & Control
Drive system typeSelf-propelled
Wheel typePlastic
Other Specs & Features
User manualClick here
SpecialIdeal for paved surfaces
Warranty3 years
Commercial warranty0.25 years
Release year2016
Release month11
Release day17
Release quarter04
Model Variants1022ER (without serrated auger)
Weight lbs with package108
Physical Specs
Width (inches)22
Height (inches)40.5
Depth (inches)46
Width (mm)558.8
Height (mm)1028.7
Depth (mm)1168.4


Also known as: Briggs and Stratton 1696847, Briggs and Stratton 208cc Single-stage Snow Blower.
