Most-complete Wacom Cintiq Pro 16 Tablet Specs

Avg. rating:
(93%) (9266 reviews over 5 sources)

You Should Also Check Out: Top 10 Best Big Tablets 2021
Main categoryBig tablet
Release year2017
Release month02

General Specs
Special features
  • Integrated stand legs
  • 20 VDC 2.25 A max power supply output
  • 33W power consumption (3W or less when asleep and 0.5W or less in sleep mode or when turned off)
  • 100 to 240 VAC (50/60Hz) power supply input
Display Size15.6in.
Display TypeIPS High-brightness panel
Display contrast1000:1
Display features
  • 345mm x 194mm active area
  • 25ms response rate
  • 6500K whitepoint default
  • Patented electromagnetic resonance method
Color Mode16777216
Display Resolution3840 x 2160
Display total pixels8294400 pixels
Display brightness250
Display's superficy (in square inches)104.04 square inches
Display's superficy (in square mm)2642.62 square mm
Dots per inch282.35 dots per inch
Physical Features
Headset Jack3.5
Available colorsBlack
Special Included Accessories
  • Wacom Pro Pen 2
  • Wacom Link (USB-C, USB-A, and Mini DisplayPort cable connectors)
  • 10 extra nibs (6 standard nib, 4 felt nib)
  • Pen holder
  • Pen stand
  • Nib removal tool
  • Cleaning cloth
  • Two color rings
Weight (grams)1500 grams
Width (inches)10.4
Height (inches)16.1
Depth (inches)0.6
Width (mm)265
Height (mm)410
Depth (mm)14.5
ConnectorsUSB-C (for up to 3840 x 2160 resolution), Mini DisplayPort (for up to 2560 x 1440 resolution)
Other Specs & Features
User manualClick here
PC data synchronizationWindows (Windows 7 or later) or Mac (OS X 10.10 or later)
CertificationsVCCI Class B, FCC Part 15 Subpart B (class B) and C, CE, IC ICES-003 and 210, RCM, KCC, BSMI, C-tick, CB, CCC, GOST-R, China RoHS, Korean RoHS, EU RoHS
Security featuresKensington MiniSaver Mobile lock slot
Special keysRadial menu
Claimed qualities
  • Supports both right-handed and left-handed use
  • Wacom’s most natural and advanced pen performance
Warranty2 years (USA, Canada, and Latin America only; 3 for Europe, Africa, China, and the Middle East and 1 for Japan and Asia Pacific)


This tablet computer (AKA Wacom DTH-1620) flaunts a top-tier 15.6-inch display, which has a resolution of 3840 x 2160 pixels and a color gamut that includes 94 percent of Adobe RGB, while it packs its premium graphic features inside an unsurprisingly-heavy 1.5-kilogram body, which makes it a challenge to carry around. Also, it does not come with ExpressKeys, unlike many of its Wacom siblings (although one can still enjoy this feature by buying the optional ExpressKeys remote) -- but offers the convenience of an enhanced 8192-pressure level Pro Pen 2.

Also called Wacom DTH-1620.
