54 Must-know Wacom MobileStudio Pro 16 i7 Tablet Specs

Main Camera
Avg. rating:
(73%) (377 reviews over 4 sources)

You Should Also Check Out: Top 10 Best Graphics Tablets 2021
Main categoryGraphics tablet
Release year2016
Release month10

General Specs
Wi-Fi802.11 ac
3D graphics
Special features
  • Intel Real Sense R200 3D scanning camera
  • 40 degrees pen tilt range
  • 8192 levels pen pressure (for both pen tip and eraser)
  • 60 levels of pen tilt recognition
  • Adjustable optional stand
  • Display toggle when attached to Mac or PC using the optional Wacom link
  • The display uses a patented electromagnetic resonance method technology
Display Size15.6in.
Display contrast800:1
Display features
  • 94-percent Adobe RGB color quality
  • Uses industry-standard pre-sets including 6500 degrees K white point display color interface, REC 709, and SRGB
Color Mode16700000
Display Resolution3840 x 2160
Display total pixels8294400 pixels
Display brightness150
Display's superficy (in square inches)104.04 square inches
Display's superficy (in square mm)2642.62 square mm
Dots per inch282.35 dots per inch
Camera Specs
Additional Camera5-megapixel
Physical Features
Available colorsBlack
Special Included Accessories
  • AC power adapter
  • Power cable
  • Cleaning cloth
  • Pen holder
  • Pen case
  • Three replacement nibs (two standard and one felt-type)
  • Color rings
  • Nib removal tool
FinishMatte black
Weight (grams)2020 grams
Width (inches)10.3
Height (inches)16.5
Depth (inches)0.7
Width (mm)262
Height (mm)418
Depth (mm)19
Operating SystemWindows 10 Pro
Processor6th-generation Intel Core i7
Graphic processorNVIDIA Quadro M1000M 4GB GDDR5
Memory ExpansionSDXC card (uhs-ii), External HDD
Battery Specs
Battery power (Wh)70 Wh (7.6 V)
Battery charging time120 minutes
Stand-by Time2.1 weeks (Equivalent to 15.0 days or 360.0 hours)
Talk time6.0 hours (360.0 minutes)
Music Playback Time6.0 hours (360.0 minutes)
3G Talk Time360.0 minutes
Usage time360 minutes
ConnectorsUSB type C (Three ports), Headset jack (for both audio and/or combo)
Bluetooth Technology4.1
TV out (through USB type C)
Music / Audio
Speaker power1.5 W (each)
Other Specs & Features
CertificationsVCCI Class B, FCC Part 15, Subpart B (class B) and C, CE, KC, BSMI, C‑tick, CB, CCC, EAC, China RoHS, Korean RoHS, EU RoHS, SII, NOM, CEL, IC, Energy Star, CEC‑BCS, Energy Label Law
Fingerprint detector
Security featuresKensington Security Slot
Special keysTwo side switches on the stylus, Expresskeys, Four-position customizable rocker ring with default touchring function, Home button, Radial menu
Claimed qualitiesThe Wacom Pro Pen 2, which comes with the tablet, has the company's "most natural and advanced pen performance" with four times greater accuracy and pressure sensitivity and has tracking capabilities that's virtually lag-free.
Warranty1 year


This model (AKA Wacom DTHW1620H) provides users with a 15.6-inch display that comes in a 3840 x 2160 resolution -- among the highest we've seen as far as 2016 is concerned, and it is prepared to take on a graphic artist's demand for memory, as its 512GB storage easily beats that of most other tablets we've seen as of 2016 -- although its 6-hour usage time may present limitations. That being said, it cements its place as a premiere graphics tablet with its Intel RealSense R200 3D scanning camera, in addition to its 8-megapixel and 5-megapixel main and front cameras, respectively.

Also called Wacom DTHW1620H.
